INJECTION MOLDING
Gharda’s G-PAEKTM product family is based on Polyether Ketone (PEK), a semi-crystalline polymer, with a high glass transition temperature of 152 °C and heat deflection temperature (HDT) of 180 °C, the unfilled G-PAEKTM grades offer solutions to many high temperature and chemically resistant applications.
Additionally, we offer various value-added filled grades with improved strength for demanding opportunities that require high wear resistance. The heat deflection temperature of these grades can be as high as 360 °C, providing strength and stability in extreme conditions. The array of Gharda G-PAEKTM product family provides a wide range of options to customers along with customized solutions wherever required.
Unfilled grades are available as powders or pellets. Filled grades are available as dry blends and compounded pellets.
Standard Unfilled PEK Polymer:
Virgin PEK polymers is available granules in following grades,
| Grades | Viscocity | Application | Datasheet |
| G-PAEKTM 1100G | High Viscocity | Injection Molding |  |
| G-PAEKTM 1200G | Standard Viscocity | Injection Molding | |
| G-PAEKTM 1300G | Medium Viscocity | Injection Molding | |
| G-PAEKTM 1400G | Low Viscocity | Injection Molding | |
Ultra High performance thermoplastic material, unreinforced Polyether Ketone (G-PAEKTM), semi-crystalline, materials may be considered as the general purpose Injection molding grades. The standard flow (1200G) and high flow (1400G) materials suitable for use in wire coating & monofilament.
We are committed to developing innovative and economically viable solutions for the need of your industries through novel technologies. Together we can find the right solutions to secure a stronger, smarter & safer future.
Contact us to learn how G-PAEKTM – Polyether Ketone (PEK) can be used to produce lighter, faster and safer products.
Glass Fiber Filled Grades
The addition of glass fiber reinforcement greatly increases the general mechanical properties at a given temperature (tensile strength, flexural strength and flexural modulus), but reduces the elongation at break.
| Grade | Glass Filled | Datasheet |
| G-PAEKTM 1215GF | 15% Glass Filled with Standard flow, Natural Beige in color and also available in Blue and Black color | |
| G-PAEKTM 1220GF | 20% Glass Filled with Standard flow, Beige in color. | |
| G-PAEKTM 1230GF | 30% Glass Filled with standard flow, Beige in color and also available in Black color | |
| G-PAEKTM 1460GF | 60% Glass Filled with standard flow, Beige in color and also available in Black color | |
We are committed to developing innovative and economically viable solutions for the need of your industries through novel technologies. Together we can find the right solutions to secure a stronger, smarter & safer future.
Contact us to learn how G-PAEKTM – Polyether Ketone (PEK) can be used to produce lighter, faster and safer products.
Carbon Fiber Filled:
Carbon fiber filled grades of PEK also have much reduced thermal expansion rates and greatly improved thermal conductivity.
| Grade | Carbon Filled | Datasheet |
| G-PAEKTM 1220CF | 20% Carbon Filled with Standard flow, Black in color. | |
| G-PAEKTM 1230CF | 30% Carbon Filled with Standard flow, Black in color. | |
| G-PAEKTM 1240CF | 40% Carbon Filled with Standard flow, Black in color. | |
We are committed to developing innovative and economically viable solutions for the need of your industries through novel technologies. Together we can find the right solutions to secure a stronger, smarter & safer future.
Contact us to learn how G-PAEKTM – Polyether Ketone (PEK) can be used to produce lighter, faster and safer products.
Wear Grades
G-PAEKTM has excellent wear resistance properties as such. Tribological grades are a combination of carbon fiber, PTFE, graphite/MoS2 reinforced in Polyether Ketone..
| Grade | Tribological Grades | Datasheet |
| G-PAEKTM 1215FC | Standard Flow, Carbon/Glass Fiber, Graphite, PTFE & MOs2 |
|
| G-PAEKTM 1230FC | Standard Flow, Carbon/Glass Fiber, Graphite, PTFE & MOs2 |
|
| G-PAEKTM 1240FC | Standard Flow, Carbon/Glass Fiber, Graphite, PTFE & MOs2 |
|
| G-PAEKTM 1250FC | Standard Flow, Carbon/Glass Fiber, Graphite, PTFE & MOs2 |
|
| G-PAEKTM 1230FCT | Standard Flow, Carbon/Glass Fiber, Graphite, PTFE & MOs2 |
|
Specific Wear Rate K0 at 1.5 m/s (m3/Nm X 10-16) of Different Wear Grades at Different Pressure
| Pressure (MPa) | G-PAEKTM1230FC | G-PAEKTM1230FCT | PBI Blend | PAI Wear grade 1 |
PAI Wear grade 2 |
PI |
| Specific Wear Rate K0 at 1.5 m/s (m3/Nm X 10-16) | ||||||
| 12.5 | 3.36 | 4.71 | 4.55 | 3.84 | 2.39 | Fail |
| 18.5 | 5.09 | 2.39 | 2.83 | Fail | 1.48 | Fail |
| 24.5 | 0.1 | 1.96 | 2.79 | Fail | 0.1 | Fail |
G-PAEKTM 1230FCT has very low wear rate: 1.96 X10-16 m3/Nm at very PV of 24.5 MPa. Also have excellent coefficient of frication: 0.1
We are committed to developing innovative and economically viable solutions for the need of your industries through novel technologies. Together we can find the right solutions to secure a stronger, smarter & safer future.
Contact us to learn how G-PAEKTM – Polyether Ketone (PEK) can be used to produce lighter, faster and safer products.
| SPECIALITY GRADE | ||
| G-PAEKTM 1220FE | 20% PTFE Filled with Standard flow, Natural Beige in colour and also available in Blue and Black colour |
|
| G-PAEKTM 1230CFM | 30% carbon Filled with Standard flow, available Black colour |
|
| G-PAEKTM 2300G | Modified PEK with improved toughness. |
|
We are committed to developing innovative and economically viable solutions for the need of your industries through novel technologies. Together we can find the right solutions to secure a stronger, smarter & safer future.
Contact us to learn how G-PAEKTM – Polyether Ketone (PEK) can be used to produce lighter, faster and safer products.
